Navy 6.0

Navy 6.0

The Navy 6.0 is the option when you need to boost your vessels power.  Equivalent to 9.9 HP it features an advanced closed loop liquid cooling system, ready for any water challenge. Like all other ePropulsion products, the Navy 6.0 is ultra-low maintenance, super quiet, and harmless to health and environment.

ePropulsion products are made from high quality raw materials which adds to their reliability.

With signification noise reduction as well as environmental impact, the Navy was specifically designed for tenders, dinghies and small sailboats up to 4 tonnes, and any other applications that require an electric outboard motor. It comes complete with throttle system, standard tiller steering mechanism, trim to 6 positions, water cooling, stem from 775mm and cables for the battery connection.

Call us now to see if Navy 6.0 is right for you

Beacon Marine - Cnr Westhaven Drive and Curran Street
(Under the Ponsonby cruising club)
09 360 0121

info@beaconmarine.co.nz

Sustainable boating

Navy 6.0 is clean, efficient and harmless on the marine environment. No fuel leak and exhaust-free. Reduce your carbon emissions for sustainable boating activities.

ePropulsion is commited to providing a green boating drive system, helping to alleviate the enviromental problems we face today.

Navy 6.0 also reduces noise pollution with 60dB maximum operating noise - the sound of a normal conversation, and field orientated control means the motor operates with less vibrations.

The Navy Battery

The Navy Battery is more than the outstanding capacity. It’s designed specifically for our Navy series, and it’s capable to discharge at the max current for hours. It looks good and perfoms even better.

Long- lasting for every ride
Advanced BMS – Safety comes first: includes six protection features
3042 Wh
A great capacity in a compact size
Aluminum Unibody Housing
Robust and thermally conductive

Each Navy battery contains a huge 312 18650 cells in total. To best optimize the performance and thermal dissipation, we design sophisticated battery arrays to create a large capacity in a compact size.

Battery Management System

Lithium-ion battery
46.8 V nominal voltage
54.6 V final charging voltage
39 V cut-off voltage
0°C - 40°C / 32˚°F - 104°F charging temperature
-20°C - 65°C / -4°F - 149°F discharging temperature
Over 80% capacity after 500 cycles of 100% DOD
3 hrs charging time

Closed Loop Cooling System

The Navy 6.0 is the first ever outboard electric motor in mass production that is equipped with a closed-loop liquid cooling system, which usually found in larger horsepower outboards.


The motor stays at a safe temperature in any tough working conditions.

A closed cooling system doesn’t require water intake, and so the entire cooling cycle stays within a closed circulation, meaning it’s more reliable
